PLANET Industrial L2+ 8-Port 10/100/1000T + 2-Port
<
>
<
>
Pildid on illustratiivsed. Nendel kujutatud toode võib erineda pakutavast või sisaldada tootekomplekti mittekuuluvaid osiseid.
TootjaPlanet
TootekoodIGS-5225-8T2S2X
Hind691,40 €
Hind (km-ta)566,72 €
Tarneaeg6-9 tp
Kogus1 tk
TransportTASUTA ÜLE EESTI!
Inbank järelmaksu kalkulaator
Tähelepanu! Järelmaks on finantskohustus,
millega kaasnevad kulud. Tutvu tingimustega siin.
Telia järelmaksu kalkulaator
Tähelepanu! Järelmaks on finantskohustus,
millega kaasnevad kulud. Tutvu tingimustega siin.
ESTO järelmaksu kalkulaator
Tähelepanu! Järelmaks on finantskohustus,
millega kaasnevad kulud. Tutvu tingimustega siin.
Switch type:
Managed
Switch layer:
L3
Quality of Service (QoS) support:
Yes
Traffic classification:
Yes
MIB support:
RFC-1213 MIB-II, IF-MIB, RFC 1493 Bridge MIB, RFC 1643 MIB, RFC 2863 MIB, RFC 2665 MIB, RFC 2819 RMON MIB (1, 2, 3, 9), RFC 2737 MIB, RFC 2618 RADIUS MIB, RFC 2933 IGMP-STD-MIB, RFC 3411 SNMP-MIB, IEEE 802.1X PAE, LLDP, MAU-MIB
Basic switching RJ-45 Ethernet ports quantity:
8
Basic switching RJ-45 Ethernet ports type:
Gigabit Ethernet (10/100/1000)
SFP module slots quantity:
2
SFP+ module slots quantity:
2
Fiber optic connector:
SFP, SFP+
Console port:
RJ-45
Networking standards:
IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1ag, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3ah, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
10G support:
Yes
Copper ethernet cabling technology:
10BASE-T, 100BASE-TX, 1000BASE-T
Port mirroring:
Yes
IP routing:
Yes
Routing entries:
32
Flow control support:
Yes
Link aggregation:
Yes
Auto MDI/MDI-X:
Yes
Auto-negotiation:
Yes
MAC address auto-learning supported:
Yes
MAC address auto-aging supported:
Yes
VLAN support:
Yes
Virtual LAN features:
Private VLAN, Tagged VLAN, Protocol-based VLAN, MAC address-based VLAN
Number of VLANs:
4095
Fiber ethernet cabling technology:
10GBASE-LR, 10GBASE-SR, 1000BASE-SX, 1000BASE‑BX, 1000BASE‑LX
MAC address table:
32000 entries
Switching capacity:
66 Gbit/s
Throughput:
44.642 Mpps
Store-and-forward:
Yes
Jumbo frames support:
Yes
Jumbo frames:
10000
Packet buffer memory:
16 MB
Access Control List (ACL):
Yes
Access Control List (ACL) rules:
123
IGMP snooping:
Yes
Security algorithms:
SNMP, SNMPv3, SSH, SSL/TLS
Authentication:
MAC-based authentication
Multicast support:
Yes
Multicast Listener Discovery (MLD) snooping:
255
Product colour:
Blue, Silver
Housing material:
Aluminium
Reset button:
Yes
LED indicators:
Activity, Link, System
International Protection (IP) code:
IP30
Wall mountable:
Yes
DIN rail mounting:
Yes
Certification:
FCC 15 A, CE, IEC60068-2-32, IEC60068-2-27, IEC60068-2-6
DC input voltage:
12 - 48 V
Output voltage:
24 V
Power consumption (max):
17.4 W
Surge protection:
Yes
Surge protection voltage:
6 kV
Power over Ethernet (PoE):
No
Operating temperature (T-T):
-40 - 75 °C
Storage temperature (T-T):
-40 - 85 °C
Operating relative humidity (H-H):
5 - 95%
Storage relative humidity (H-H):
5 - 95%
Heat dissipation:
55.79 BTU/h
Width:
76.8 mm
Depth:
107.3 mm
Height:
152 mm
Weight:
1.07 kg
Harmonized System (HS) code:
85176990
Terminal block port:
Yes
