GIGABYTE X870 AORUS ELITE WIFI7 Motherboard - Supports AMD Ryzen 9000 CPUs, 16+2+2 phases VRM, up to 8000MHz DDR5 (OC), 3xPCIe 5.0 + 1xPCIe 4.0, Wi-Fi 7, 2.5GbE LAN, USB 4
<
>
<
>
Images are illustrative. The product shown may differ from the one offered or include components not part of the product set.
VendorGigabyte
Product codeX870 AORUS ELITE WIFI7
Warranty
3 years
Price€288.00
Price (excl. VAT)€232.26
Ships in
3-5 bd
Quantity5+ pcs
Inbank financing calculator
NB! Järelmaks on finantskohustus,
millega kaasnevad kulud. Tutvu tingimustega siin.
Telia financing calculator
NB! Järelmaks on finantskohustus,
millega kaasnevad kulud. Tutvu tingimustega siin.
ESTO financing calculator
NB! Järelmaks on finantskohustus,
millega kaasnevad kulud. Tutvu tingimustega siin.
Ships quicker
Warranty period:
3 year(s)
Supported processor sockets:
Socket AM5
Compatible processor series:
AMD Ryzen 9000 Series, AMD Ryzen 7000 Series, AMD Ryzen 8000 Series
Processor manufacturer:
AMD
Processor socket:
Socket AM5
Maximum internal memory supported by processor:
256 GB
Parallel processing technology support:
Not supported
DirectX version:
12.0
On-board graphics card:
No
PC health monitoring:
Voltage, Temperature, Fan
Windows operating systems supported:
Windows 11 x64
Audio chip:
Realtek ALC1220
Motherboard chipset family:
AMD
Product colour:
Black
Audio output channels:
7.1 channels
Motherboard form factor:
ATX
Motherboard chipset:
AMD X870
Supported memory clock speeds:
6400, 6800, 6200, 6666, 6600, 6000, 5600, 4400, 4800, 5200, 8000, 7600, 7800, 7000, 8200, 7200
Supported memory module capacities:
24GB, 32GB, 1GB, 8GB, 16GB, 2GB, 4GB
Maximum internal memory:
256 GB
ECC сompatibility:
Non-ECC
Memory slots type:
DIMM
Memory channels:
Dual-channel
Supported memory types:
DDR5-SDRAM
Number of memory slots:
4
Maximum internal memory per slot:
64 GB
Supported memory clock speed (max):
8200 MHz
Depth:
244 mm
Width:
305 mm
Height:
35 mm
Bluetooth:
Yes
LAN controller:
Realtek RTL8125
Top Wi-Fi standard:
Wi-Fi 7 (802.11be)
Ethernet LAN:
Yes
WLAN controller model:
MediaTek MT7925
Wi-Fi standards:
Wi-Fi 7 (802.11be)
Wi-Fi:
Yes
Ethernet interface type:
2.5 Gigabit Ethernet
Bluetooth version:
5.4
Front panel connector:
Yes
USB 2.0 connectors:
2
CPU fan connector:
Yes
EPS power connector (8-pin):
Yes
ATX Power connector (24-pin):
Yes
Front panel audio connector:
Yes
Number of chassis fan connectors:
6
USB 3.2 Gen 1 (3.1 Gen 1) connectors:
1
Number of SATA III connectors:
4
USB 3.2 Gen 2x2 connectors:
1
RGB LED pin header:
Yes
Number of RGB LED pin headers:
4
TPM connector:
Yes
Number of water pump connectors:
3
Number of CPU fan connectors:
2
Number of EPS power connectors (8-pin):
2
Clear CMOS button:
Yes
BIOS type:
UEFI AMI
Clear CMOS jumper:
Yes
Desktop Management Interface (DMI) version:
2.7
Batteries included:
Yes
Antenna included:
Yes
Screws included:
Yes
Supported storage drive types:
HDD & SSD
Supported storage drive interfaces:
M.2, SATA III
RAID support:
Yes
RAID levels:
10, 0, 1
Number of HDDs supported:
4
Number of storage drives supported:
8
DisplayPort version:
1.4
USB 2.0 ports quantity:
2
Ethernet LAN (RJ-45) ports:
1
DisplayPorts quantity:
2
S/PDIF out port:
Yes
WiFi-AP antenna jack:
2
HDMI ports quantity:
1
HDMI version:
2.1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity:
3
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity:
4
Microphone in:
Yes
Headphone outputs:
1
USB4 Gen 2x2 ports quantity:
2
Number of M.2 (M) slots:
4
PCI Express x16 (Gen 3.x) slots:
1
PCI Express x16 (Gen 4.x) slots:
1
3rd M.2 highest PCI Express generation:
5.0
1st M.2 largest key size:
25110
PCI Express x16 (Gen 5.x) slots:
1
2nd M.2 highest PCI Express generation:
5.0
PCI Express x4 slots:
2
4th M.2 largest key size:
22110
2nd M.2 largest key size:
22110
1st M.2 highest PCI Express generation:
5.0
3rd M.2 largest key size:
22110
4th M.2 highest PCI Express generation:
4.0
Battery technology:
Lithium-Manganese Dioxide (LiMnO2)
Number of battery cells:
1
Battery weight:
3 g
Battery type:
CR2032
Lithium weight per battery:
0.07 g
Weight:
2.4 kg
Country of origin:
China
Products per shipping (inner) case:
1 pc(s)
Warnings:
Do not disassemble to avoid damage to internal components and loss of warranty., Dispose of in accordance with local regulations for electronic waste., Avoid contact with liquids to prevent electronic damage.
