GIGABYTE Z790 AORUS ELITE AX Motherboard - Supports Intel Core 14th CPUs, 16*+2+１ Phases Digital VRM, up to 7600MHz DDR5 (OC), 4xPCIe 4.0 M.2, Wi-Fi 6E, 2.5GbE LAN, USB 3.2 Gen 2x2
<
>
<
>
Pildid on illustratiivsed. Nendel kujutatud toode võib erineda pakutavast või sisaldada tootekomplekti mittekuuluvaid osiseid.
VendorGigabyte
Product codeZ790 AORUS ELITE AX
Warranty
3 years
Price€240.80
Price (excl. VAT)€197.38
Delivery3-5 workdays
Quantity5+ pcs
TransportFREE IN ESTONIA!
Inbank financing calculator
NB! Järelmaks on finantskohustus,
millega kaasnevad kulud. Tutvu tingimustega siin.
Telia financing calculator
NB! Järelmaks on finantskohustus,
millega kaasnevad kulud. Tutvu tingimustega siin.
ESTO financing calculator
NB! Järelmaks on finantskohustus,
millega kaasnevad kulud. Tutvu tingimustega siin.
Ships quicker
Warranty period:
3 year(s)
Compatible processor series:
Intel® Core™ i5, Intel® Celeron®, Intel® Core™ i3, Intel® Core™ i7, Intel® Core™ i9, Intel® Pentium® Gold
Processor manufacturer:
Intel
Maximum internal memory supported by processor:
192 GB
Supported processor sockets:
LGA 1700
Processor socket:
LGA 1700
Maximum resolution:
4096 x 2304 pixels
On-board graphics card:
No
Parallel processing technology support:
CrossFire
HDCP:
Yes
DirectX version:
12.0
Motherboard chipset family:
Intel
Windows operating systems supported:
Windows 10 x64, Windows 11 x64
Audio output channels:
7.1 channels
Motherboard form factor:
ATX
PC health monitoring:
Fan, Water cooling, Voltage, Temperature
Motherboard chipset:
Intel Z790
Product colour:
Black
Memory channels:
Dual-channel
Supported memory clock speed (max):
7600 MHz
Memory slots type:
DIMM
Supported memory types:
DDR5-SDRAM
Number of memory slots:
4
ECC сompatibility:
ECC & Non-ECC
Supported memory clock speeds:
7600, 5200, 6200, 6000, 5800, 5400, 6800, 5600, 7200, 7000, 7400, 6600, 6400, 4000, 4800
Unbuffered memory:
Yes
Maximum internal memory:
192 GB
Width:
305 mm
Depth:
244 mm
Height:
35 mm
Ethernet interface type:
2.5 Gigabit Ethernet
Wi-Fi standards:
802.11b, 802.11a, Wi-Fi 6 (802.11ax), Wi-Fi 4 (802.11n), 802.11g, Wi-Fi 6E (802.11ax), Wi-Fi 5 (802.11ac)
Ethernet LAN:
Yes
Top Wi-Fi standard:
Wi-Fi 6E (802.11ax)
WLAN controller model:
Intel Wi-Fi 6E AX211
Bluetooth version:
5.3
Wi-Fi:
Yes
Bluetooth:
Yes
Front panel connector:
Yes
EPS power connector (8-pin):
Yes
USB 3.2 Gen 2 (3.1 Gen 2) connectors:
1
Number of SATA III connectors:
6
TPM connector:
Yes
Front panel audio connector:
Yes
ATX Power connector (24-pin):
Yes
Total number of SATA connectors:
6
CPU fan connector:
Yes
USB 3.2 Gen 1 (3.1 Gen 1) connectors:
1
RGB LED pin header:
Yes
12V power connector:
Yes
USB 2.0 connectors:
2
Thunderbolt headers:
2
Clear CMOS jumper:
Yes
Clear CMOS button:
Yes
BIOS type:
UEFI AMI
Desktop Management Interface (DMI) version:
2.7
Cables included:
SATA
Batteries included:
Yes
Number of HDDs supported:
6
RAID levels:
0, 10, 1, 5
RAID support:
Yes
Number of storage drives supported:
10
Supported storage drive interfaces:
M.2, PCI Express 4.0, SATA III
Supported storage drive types:
HDD & SSD
USB 2.0 ports quantity:
4
DisplayPort version:
1.2
HDMI ports quantity:
1
Microphone in:
Yes
Ethernet LAN (RJ-45) ports:
1
USB connector type:
USB Type-C, USB Type-A
USB 3.2 Gen 2x2 Type-C ports quantity:
1
Headphone outputs:
2
HDMI version:
2.0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity:
3
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity:
2
WiFi-AP antenna jack:
2
DisplayPorts quantity:
1
S/PDIF out port:
Yes
Number of M.2 (M) slots:
4
PCI Express x16 slots:
3
Battery type:
CR2032
Battery technology:
Lithium-Manganese Dioxide (LiMnO2)
Battery weight:
3 g
Number of battery cells:
1
Lithium weight per battery:
0.07 g
Products per shipping (inner) case:
1 pc(s)
Country of origin:
China
Warnings:
Do not dispose of the motherboard in the ordinary rubbish bin; the product requires special disposal., Before starting any maintenance or installation, disconnect the product from the power supply., Avoid direct contact with electronics to prevent electrostatic damage.
